Structure of the Atom

According to J.J. Thomson’s model of an atom, it consists of a positively charged sphere with neutrons embedded in it. However, it was later found that the positively charged particles reside at the center of the atom called the nucleus, and the electrons revolve around the nucleus.
Moreover, Thomson attributed that the mass of an atom due to electrons and protons are evenly spread throughout the atom. This is not in agreement with the observations of Rutherford who concluded that mass is concentrated in a very small space in the center of the atom later called nucleus.

According to Rutherford’s model of an atom, electrons revolvearound the nucleus in fixed circular orbits. We know, any particle revolving in a circular orbit would experience acceleration. Due to this acceleration, the electrons revolving in circular orbits will lose energy in the form of radiation and finally fall into the nucleus. In such a case, atom would be highly unstable which is not true.

Bohr’s model of Atom According to Bohr’s theory:

1. The atom consists of a small positively charged nucleus at its center.
2. The whole mass of the atom is concentrated at the nucleus and the volume of the nucleus is much smaller than the volume of the atom.
3. All the protons and neutrons of the atom are contained in the nucleus.
4. Only certain orbits known as discrete orbits of electrons are allowed inside the atom.
5. While revolving in these discrete orbits electrons do not radiate energy. These orbits or cells are represented by the letters K, L, M, N etc. or the numbers, n = 1, 2, 3, 4, . . as shown in the above figure.

Following rules are followed to fill electrons in different energy levels.

1. If n gives the number of orbit or energy level, then 2n2 gives the maximum number of electrons possible in a given orbit or energy level. Thus,
   First orbit or K-shell will have 2 electrons,
   Second orbit or L-shell will have 8 electrons,
   Third orbit or M-shell will have 18 electrons.
2. If it is the outermost orbit, then it should have not more than 8 electrons.
3. There should be step-wise filling of electrons in different orbits, i.e., electrons are not accompanied in a given orbit if the earlier orbits or shells are incompletely filled.

The valency of an element is the combining capacity of that element. The valency of an element is determined by the number of valence electrons present in the atom of that element.
If the number of valence electrons of the atom of an element is less than or equal to four, then the valency of that element is equal to the number of valence electrons. For example, the atom of silicon has four valence electrons and so, it has valency equal to four.
On the other hand, if the number of the number of valence electrons of the atom of an element is greater than 4, then the valency of that element is obtained by subtracting the number of valence electrons from 8. For example, the atom of oxygen has 6 valence electrons. and so, the valency of oxygen is (8 – 6) 2.

Atomic Number is defined as the number of protons present in the nucleus ofan atom. For example, there are 6 protons in carbon, so the atomic number of carbon is 6. All atoms are characterized by their atomic numbers.
Mass Number is defined as the sum of the total number of protons and neutrons present in the nucleus of an atom. For example, there are 6 protons and 6 neutrons in the nucleus of carbon, so its mass number is 12.
Isotopes are atoms of the same element thus having same atomic number but different mass number. For example, chlorine has two isotopes with atomic number 17 but mass numbers 35 and 37 represented by -

Two Uses of Isotopes

(a) Isotope of cobalt (60Co) is used in the treatment of cancer.
(b) Isotope of uranium (235U) is used as a fuel in nuclear reactors. Isobars are such atoms which have same mass number but different atomic numbers. Thus, isobars are different elements. For example, Ne has atomic number 10 and sodium has atomic number 11 but both of them have massnumbers as 22 represented by -

The atomic number of sodium is 11. So, neutral sodium atom has 11 electrons and its electronic configuration is 2, 8, 1. But Na+ has 10 electrons. Out of 10, K-shell contains 2 and L-shell 8 electrons respectively. Thus, Na+has completely filled K and L shells.

Isotope of bromine with atomic mass 79 u = 49.7% Contribution of 79Br to atomic mass of bromine

If Z=3, i.e., atomic number is 3. The element is lithium and has distribution of electrons as 2, 1. and so, lithium has a valency of 1.

Mass number of X = 6 + 6 = 12
Mass number of Y = 6 + 8 = 14
Since X and Y both have atomic numbers as 6 but mass numbers are different, therefore, these are isotopes.

(a) F (b) F (c) T (d) T

(a) √ (b) X (c) X (d) X

(a) X (b) X (c) √ (d) X

(a) X (b) √ (c) X (d) X

(d)
